The class to handle EEP D232 Automated meter reading (AMR) profiles. More...

#include <eoEEP_D232xx.h>

Inheritance diagram for eoEEP_D232xx:

[legend]

Collaboration diagram for eoEEP_D232xx:

[legend]

Public Member Functions
eoReturn	SetType (uint8_t type)

virtual eoReturn	GetValue (CHANNEL_TYPE type, float &value, uint8_t index)
	Gets the Value as Floating point. More...

virtual eoReturn	SetValue (CHANNEL_TYPE type, float value, uint8_t index)
	Gets the Value as a float. More...

Public Member Functions inherited from eoD2EEProfile
	eoD2EEProfile (uint16_t size=14)

virtual eoReturn	CreateTeachIN (eoMessage &m)
	Generates an EEP Telegram(only not chained supported!!1) More...

virtual eoReturn	SetCommand (uint8_t cmd)

Public Member Functions inherited from eoEEProfile
	eoEEProfile (uint16_t size=4)

virtual eoReturn	GetValue (CHANNEL_TYPE type, float &value)
	Gets the Value as Floating Point. More...

virtual eoReturn	GetValue (CHANNEL_TYPE type, uint8_t &value)
	Sets the Value using a unsigned integer. More...

virtual eoReturn	GetValue (CHANNEL_TYPE type, uint32_t &value)

virtual eoReturn	GetValue (CHANNEL_TYPE type, uint8_t &value, uint8_t subFlag)
	Gets the Value as unsigned integer. More...

virtual eoReturn	GetValue (CHANNEL_TYPE type, uint32_t &value, uint8_t subFlag)

virtual eoReturn	GetValue (CHANNEL_TYPE type, uint64_t &value, uint8_t subFlag)

virtual eoReturn	SetValue (CHANNEL_TYPE type, float value)
	Sets the Value using a Floating Point. More...

virtual eoReturn	SetValue (CHANNEL_TYPE type, uint8_t value)
	Sets the Value using a uint8_t. More...

virtual eoReturn	SetValue (CHANNEL_TYPE type, uint32_t value)

virtual eoReturn	SetValue (CHANNEL_TYPE type, uint8_t value, uint8_t subFlag)
	Gets the Value as unsigned integer. More...

virtual eoReturn	SetValue (CHANNEL_TYPE type, uint32_t value, uint8_t subFlag)

virtual eoReturn	SetValue (CHANNEL_TYPE type, uint64_t value, uint8_t subFlag)
	Sets the Value as a 64-bit. More...

virtual eoChannelInfo *	GetChannel (CHANNEL_TYPE type, uint8_t subType)

virtual eoChannelInfo *	GetChannel (CHANNEL_TYPE type)

virtual eoChannelInfo *	GetChannel (uint8_t channelNumber)

virtual eoReturn	GetSubTypeChannel (CHANNEL_TYPE type, std::vector< eoEEPChannelInfo *> &vector)

virtual uint8_t	GetChannelCount () const

Public Member Functions inherited from eoProfile
	eoProfile (uint16_t size=0)

virtual bool	operator== (const eoProfile &othProfile) const

virtual bool	operator!= (const eoProfile &othProfile) const

virtual bool	IsSecDData (const eoMessage &message)

virtual void	ClearValues ()

virtual eoReturn	Create (eoMessage &m)
	Generates an EEP Message. More...

virtual eoReturn	Parse (const eoMessage &msg)
	Parses a msg using learned in Profile from Device. More...

virtual uint8_t	Serialize (eoArchive &a)
	Serialization Function which will be called by the eoStorageManager. More...

eoReturn	SetManufacturer (uint16_t manufacturerID)

Additional Inherited Members
Public Attributes inherited from eoProfile
uint8_t	rorg
	R-ORG.

uint8_t	func
	Func.

uint8_t	type
	Type.

uint16_t	manufacturer
	Manufacturer.

Static Protected Member Functions inherited from eoEEProfile
static void	CopyItemToChannel (eoEEPChannelInfo &channel, EEP_ITEM const *item)

Static Protected Member Functions inherited from eoProfile
static float	ScaleFromRAW (uint32_t rawValue, uint32_t rangeMin, uint32_t rangeMax, double scaleMin, double scaleMax)
	Creates floating Point from Raw Value. More...

static uint32_t	ScaleToRAW (float value, uint32_t rangeMin, uint32_t rangeMax, double scaleMin, double scaleMax)
	Creates Raw Value from a floating Point. More...

static eoReturn	GetRawValue (const eoMessage &msg, uint32_t &value, uint16_t offset, uint8_t size)
	Gives raw data Value from a Message. More...

static eoReturn	SetRawValue (eoMessage &msg, uint32_t value, uint16_t offset, uint8_t size)
	Inserts raw data Value in a message. More...

Protected Attributes inherited from eoEEProfile
eoEEPChannelInfo *	channel
	ChannelInfo list for direct Access to channels.

uint8_t	channelCount
	Number of channels.

Protected Attributes inherited from eoProfile
eoMessage	msg
	helper function to convert bits

Static Protected Attributes inherited from eoProfile
static const uint8_t	maskArray [8]
	Mask array.

Detailed Description

The class to handle EEP D232 Automated meter reading (AMR) profiles.

Allows the user to handle EEP D232 Automated meter reading (AMR) profiles, the following profiles are available:

D2-32-00
D2-32-01

D2-32-02
The following channels are available for Profile 0:

Channel Index	Channel Type	Type	Comment
0	F_ON_OFF	uint8_t
1	S_CURRENT	float	Channel 1, CURR_CHANNEL_1

The following channels are available for Profile 1:

Channel Index	Channel Type	Type	Comment
0	F_ON_OFF	uint8_t
1	S_CURRENT	float	Channel 1, CURR_CHANNEL_1
2	S_CURRENT	float	Channel 2, CURR_CHANNEL_2

The following channels are available for Profile 2:

Channel Index	Channel Type	Type	Comment
0	F_ON_OFF	uint8_t
1	S_CURRENT	float	Channel 1, CURR_CHANNEL_1
2	S_CURRENT	float	Channel 2, CURR_CHANNEL_2
3	S_CURRENT	float	Channel 3, CURR_CHANNEL_3

Member Function Documentation

◆ GetValue()

virtual eoReturn eoEEP_D232xx::GetValue	(	CHANNEL_TYPE	type,
		float &	value,
		uint8_t	subFlag
	)

virtual

Gets the Value as Floating point.

Using the CHANNEL_TYPE type information, this information gets the unsigned integer value accordingly, if the Profile does not support the requested CHANNEL_TYPE NOT_SUPPORTED is returned, if the functions is not implemented for the chosen profile, NOT_IMPLEMENTED is returned

Parameters

type	CHANNEL_TYPE
value	Reference to floating point
subFlag	Sub flag

Returns: eoReturn EO_OK,NOT_SUPPORTED,NOT_IMPLEMENTED

Reimplemented from eoEEProfile.

◆ SetType()

eoReturn eoEEP_D232xx::SetType ( uint8_t type )

virtual

Sets and checks if the specified [EEP] type is supported

Parameters

type

Returns: eoReturn EO_OK or NOT_SUPPORTED

Reimplemented from eoProfile.

◆ SetValue()

virtual eoReturn eoEEP_D232xx::SetValue	(	CHANNEL_TYPE	type,
		float	value,
		uint8_t	subFlag
	)

virtual

Gets the Value as a float.

Using the CHANNEL_TYPE type information, this information gets the unsigned integer value accordingly, if the Profile does not support the requested CHANNEL_TYPE NOT_SUPPORTED is returned, if the functions is not implemented for the chosen profile, NOT_IMPLEMENTED is returned

Parameters

type	CHANNEL_TYPE
value	Reference to floating point
subFlag	Sub flag

Returns: eoReturn EO_OK,NOT_SUPPORTED,NOT_IMPLEMENTED

Reimplemented from eoEEProfile.
